| Двигатель и топливная система |
|---|
| Модель двигателя | Kubota D1305
|
|---|
| Объем двигателя | 1.3L
|
|---|
| Engine Oil W/ Filter Change | 5.9L
|
|---|
| Тип топлива | Дизельное топливо
|
|---|
| Топливный бак | 30L
|
|---|
|
| Габариты и масса |
|---|
| Полная высота | 2500mm
|
|---|
| Operating Weight(Canpoy) | 2860kg
|
|---|
|
| Гидравлическая система |
|---|
| Hydraulic Tank - Total System | 55L
|
|---|
|
| Ходовая часть |
|---|
| Minimum Ground Clearance | 290mm
|
|---|
|
| Технические характеристики |
|---|
| Tail Swing Radius | 750mm
|
|---|
| Overall Track Length | 1970mm
|
|---|
| Overall Track Width | 1550mm
|
|---|
| Overall Transport Length | 4180mm
|
|---|
| Track Shoe Width | 300mm
|
|---|
| Arm (Standard Length) | 1.13m
|
|---|
| Emissions Certification | TIER 4 FINAL
|
|---|
| Cylinders | 3
|
|---|
| Gross Horsepower – Sae J1995 | 18.5kw
|
|---|
| Fuel Injection | Mechanical
|
|---|
| Cooling Method | Water-cooled
|
|---|
| Travel Speeds - 1st | 2.5 км/ч
|
|---|
| Travel Speeds - 2nd | 4.4 км/ч
|
|---|
| Maximum Traction Force | 21.4kN
|
|---|
| Gradeability | 30°
|
|---|
| Radiator | 5L
|
|---|
| Maximum Dig Radius | 4650mm
|
|---|
| Dig Radius At Groundline | 4515mm
|
|---|
| Maximum Dig Depth | 2500mm
|
|---|
| Backfill Blade Height | 330mm
|
|---|
| Backfill Blade Width | 1550mm
|
|---|
| Backfill Blade Dig Depth | 450mm
|
|---|
|
